Actuators and Sensors in a Mechatronic System - 1

Sensors

Sensor is a device that when exposed to a physical phenomenon (temperature, displacement, force, etc.) produces a proportional output signal (electrical, mechanical, magnetic, etc.). The term transducer is often used synonymously with sensors. However, ideally, a sensor is a device that responds to a change in the physical phenomenon. On the other hand, a transducer is a device that converts one form of energy into another form of energy. Sensors are transducers when they sense one form of energy input and output in a different form of energy. For example, a thermocouple responds to a temperature change (thermal energy) and outputs a proportional change in electromotive force (electrical energy). Therefore, a thermocouple can be called a sensor and or transducer.



 Actuators

Actuators are basically the muscle behind a mechatronics system that accepts a control command (mostlyin the form of an electrical signal) and produces a change in the physical system by generating force, motion, heat, flow, etc. Normally, the actuators are used in conjunction with the power supply and a coupling mechanism. The power unit provides either AC or DC power at the rated voltage and current. The coupling mechanism acts as the interface between the actuator and the physicalsystem. Typical mechanisms include rack and pinion, gear drive, belt drive, lead screw and nut, piston,and linkages.
